Pertronix 40501 Ignition C Oil

PERTRONIX FLAME-THROWER COIL 40,000 VOLT 3.0 OHM CHROME
Part Number: 40501
FLAME-THROWER COIL. 40,000-VOLT RATED WITH 3.0-OHMS OF RESISTANCE. CHROME OIL FILLED CANISTER STYLE.

• Ignition Coil Model Or Series: Flame-Thrower
• Coil Type: Canister
• Maximum Voltage: 40,000 Volts
• Primary Resistance: 3.0 Ohms
• Secondary Resistance: 9.0k Ohms
• Coil Wire Attachment: Socket
• Height: 6.000"
• Diameter: 2.150"
• Finish: Chrome
• Internal Construction: Oil Filled
• Primary Inductance: 10.0 mH
• Turns Ratio: 80:1
• Includes Mounting Bracket: No
• Includes Ballast Resistor: No
• Includes Hardware: No
• Quantity: Sold As Each

The Flame-Thrower canister style coil has been engineered to complement our Ignitor Electronic Ignition Conversion Kits and Plug n’ Play Distributors. Choose from the Flame-Thrower, Flame-Thrower II, and the Flame-Thrower III depending upon system voltage and resistance. Oil filled coils offer great heat control for street driven vehicles, while epoxy filled coils provide superior winding support for high vibration environments in off-road vehicles and boats.

• 40,000 volts.
• For use with inductive ignition systems.
• 1.5 or 3.0 Ohm primary resistance values available.
• Legal in all 50 states and Canada. (C.A.R.B. E.O. #D-57-21)

The Flame Thrower canister coil is designed to mate with the Ignitor Electronic Conversion Kit, but can benefit virtually any distributor type inductive systems. Higher voltage allows larger spark plug gap for added power, smoother response, and improved fuel economy.
